Professional Cardboard Grooving
Machine Manufacturer
Main function:
- Automatic feeding , board feeding with more smoothly and more higher speed.
- Use PLC to control the cutting length of corners.
- In order to achieve high accuracy of corner cutting which is used the Japan high frequency electromagnet . It brings higher speed and stability.
- If you don’t use corner cutting function ,you can close it .And only use grooving function .
- Adopt the 2 dedicate conveyor belt to automatic receive the half-finished and whole finished board.
- Remove the waste corner and chip automatically by 2 dedicate conveyor belts ,it save labor, and improve the efficiency.
|
Multi-function machine |
Automatic corner cutting and grooving machine SLG-830 |
|
Thickness |
1-3.5mm |
|
Material length |
130-550mm |
|
Material width |
130-850mm |
|
Best grooving accuracy |
±0.05mm |
|
Cutting accuracy |
≦2mm |
|
Corner cutting length (corner size) |
Min.13mm (13*13mm) |
|
Groove distance (if blades are on the same girder ) |
Min70mm |
|
Groove distance (if blades are on two girders) |
No limit |
|
V Grooving knife |
12 sets (12 knives in 3 rows) |
|
Grooving angle |
90º and 120º tools to adjust v shape from 85-135º each grooving knife can be adjusted independently |
|
U grooving blade |
As per customized |
|
PLC |
Omron /MCGS TBC7062 |
|
Sensor |
Omron/Panasonic |
|
Relay |
German Muller |
|
Electromagnet controller |
Japan |
|
Inverter |
Senlan/ Siemens/Panasonic/Schneider |
|
Speed |
100-120 PCS/Min |
|
Power |
5KW |
|
Dimension |
3400*1450*2150mm |
|
Weight |
3500KGS |
|
Useful tool |
1 box |
|
