Professional Cardboard Grooving
Machine Manufacturer
Main advantages :
- Feida feeding system ,to avoid the scratch problem of material surface .
- Paperboard 90 degree turn around system---mainly through the middle drum ,high speed,high stability ,no scratch.
- Two dedicated conveyor belt for removing the waste material out of the machine .
- Automatic collector holder for final product : to save time and man power .
|
Function |
Technical parameter |
|
Material size of 1st step |
Length 195-560mm ,width 195-560mm |
|
Material size of 2nd step |
Length 195-560mm, width 195-560mm |
|
Grooving knives of 1st step |
6 sets |
|
Grooving knives of 2nd step |
6 sets |
|
Best accuracy |
±0.05mm |
|
Normally accuracy |
±0.1mm |
|
Material thickness |
200-350GSM |
|
Grooving angle |
80-140 degree adjustable , (90º=80º-110º ,120º=110º-140º) |
|
Speed |
Normally :80PCS/Min Fast :120PCS/Min |
|
Quantity of girder (crossbeam ) |
2 sets |
|
Quantity of knife row |
3 rows ( 1 rows of knives on the 1st girder, 2 rows of knives on the 2nd girder ) |
|
The way of feeding paper |
Feida air feeding system |
|
Platform type of adding paper |
Upper and lower platform ( save the time of paper putting ) |
|
Adjustable knife left position or right |
By manual |
|
Grooving depth |
Adjust the girder by manual |
|
Rolling belt adjustment |
Remove the belt quickly by handwheel |
|
Waste cleaning system |
Automatic waste cleaning system with air system+ 2 dedicated conveyor belts |
|
Weight |
3000KGS |
|
Power |
6.0KW |
|
Machine dimension |
3200*2950*1570mm |
|
Edge correction principle of 1st step |
Belt correction + steel ball correction |
|
Edge correction principle of 2st step |
Belt correction + steel ball correction |
|
90º turn around system ( direction change ) |
Drum flipping |
